NNC Waterproof Micro Switch NFW6 series for electronics, machinery and light industry

Brand Name : NNC

Model Number : NFW6 Series

Certification : CE/CCC

Place of Origin : China

MOQ : 500pcs

Price : get latest price

Payment Terms : T/T

Supply Ability : 2k pcs 7 days

Delivery Time : 7-14 days

Operating Speed : 0.1mm-1m/s

Contact Resistance : 50mΩ max

Insulation Resistance : ＞100MΩ（at 500VDC）

Endurance : Mechanical: 500,000 operations min.; Electrical: 10,000operations min.

Dielectric Strength : Between current carrying metal parts and ground: AC1500V,50/60Hz for 1min

Operating Ambient : -25℃~+125℃; ＜60%RH

Protection level : IP67
