NNC miniature weight Limit Switch ESL4V series for electronics, machinery and light industry

Product Categories

CLION ELECTRIC CO.,LTD

Contact Now

Brand Name : NNC

Model Number : ESL4V

Certification : CE/TUV/UL/CQC

Place of Origin : China

MOQ : 500pcs

Price : get latest price

Payment Terms : T/T

Supply Ability : 2k pcs 7 days

Delivery Time : 7-14 days

Operating Speed : 5mm/s-0.5m/s

Operating Frequency : Mechanical: 120operations/min; Electrical: 30 operationss/min

Contact Resistance : ＜25mΩ

Insulation Resistance : ＞100MΩ（＜500VDC）

Weigth : approx.135g

Ambient temperature : -20℃~70℃; ＜95%RH

Protection level : IP65

Dielectric strength : between current carrying metal part and ground:1500VAC,50/60Hz for 1min

Contact Now

ESL4V Series Limit Switch

Features

1.Double circuit limit switch

2.Wide variety of actuator shapes to match the operating environment and application

3.Compact size design

4.Fully open terminal structure for easy wiring
